Pelvis X-Ray: A Comprehensive Guide

A pelvis X‑ray is a quick imaging test that visualizes the hip bones, sacrum, coccyx, and surrounding joints. It helps diagnose fractures, dislocations, arthritis, congenital abnormalities, and trauma‑related injuries, supporting accurate orthopedic and emergency assessment.

Introduction

The pelvis X-ray is a fundamental diagnostic imaging test widely used in clinical medicine to evaluate a variety of conditions affecting the pelvic region. This article provides an in-depth overview of the pelvis X-ray, including its purpose, procedure, indications, interpretation, risks, patient preparation, and clinical significance. Designed for medical students, clinicians, and patients, this guide aims to deliver clear, evidence-based information while avoiding unnecessary jargon and repetition.

Anatomy of the Pelvis: Structures Visualised

The pelvis is a complex bony structure that forms the base of the spine and supports the lower limbs. It consists of the sacrum, coccyx, and two hip bones (each comprising the ilium, ischium, and pubis). A pelvis X-ray typically visualises:

• The iliac crests
• Acetabula (hip sockets)
• Pubic symphysis
• Sacroiliac joints
• Proximal femora (upper thigh bones)
• Sacrum and coccyx

Understanding the normal anatomy is essential for accurately interpreting pelvis X-rays and identifying pathological changes.

Indications: When Is a Pelvis X-Ray Ordered?

Pelvis X-rays are ordered for a variety of clinical reasons, including but not limited to:

• Trauma: To assess for fractures or dislocations following falls, road traffic accidents, or sports injuries.
• Chronic pain: Investigation of unexplained pelvic, hip, or lower back pain.
• Arthritis: Evaluation of degenerative changes or inflammatory joint diseases.
• Infection: Suspected osteomyelitis, septic arthritis, or pelvic abscess.
• Tumours: Detection of primary bone tumours or metastatic lesions.
• Congenital abnormalities: Assessment of developmental dysplasia of the hip (particularly in children).
• Pre-operative planning: Prior to hip or pelvic surgery.
• Follow-up: Monitoring healing of fractures or post-surgical changes.

Contraindications: When Should the Test Be Avoided?

While pelvis X-rays are generally safe, there are situations where their use may be limited or avoided:

• Pregnancy: Due to potential risks of radiation exposure to the fetus, alternative imaging (e.g., ultrasound or MRI) is often preferred unless the benefits outweigh the risks.
• Inability to cooperate: Patients unable to remain still may produce poor-quality images, sometimes necessitating sedation or alternative imaging.
• Repeat imaging: Cumulative radiation exposure should be minimised, especially in young patients.

In these cases, clinicians must carefully weigh the necessity of the X-ray against potential risks and consider alternative modalities where possible.

Preparation: Patient Instructions and Considerations

Preparation for a pelvis X-ray is typically straightforward, but proper patient instructions are essential to ensure image quality and safety:

• Clothing: Patients are usually asked to change into a hospital gown and remove all clothing and jewellery from the waist down to avoid artifacts on the image.
• Pregnancy status: Female patients of childbearing age should inform the radiographer if they are or might be pregnant.
• Bladder preparation: In some cases, patients may be asked to empty their bladder before the procedure for optimal image clarity.
• Communication: Patients should inform staff of any recent pelvic surgery, implants, or devices that might interfere with imaging.

Procedure: Step-by-Step Guide

The pelvis X-ray is a quick, non-invasive procedure usually performed in the radiology department. The typical steps are as follows:

1. Patient positioning: The patient lies supine (on their back) on the X-ray table. Legs are often rotated slightly inward to provide a clear view of the hip joints.
2. Shielding: A lead apron may be used to shield non-target areas, especially the reproductive organs, from radiation exposure.
3. Image acquisition: The radiographer positions the X-ray tube above the pelvis and instructs the patient to remain still. One or more images are taken, usually in the anteroposterior (AP) projection. Additional views (e.g., lateral, inlet, outlet) may be obtained if clinically indicated.
4. Completion: The procedure typically lasts 5-10 minutes. Patients can resume normal activities immediately unless otherwise advised.

Special considerations may apply in trauma cases, where images may be obtained without moving the patient to prevent further injury.

Interpretation: Reading the Pelvis X-Ray

Interpretation of pelvis X-rays requires systematic analysis to detect abnormalities. Radiologists and clinicians typically assess:

• Bony alignment: Looking for dislocations or subluxations of the hip or sacroiliac joints.
• Fractures: Identification of breaks, their location (e.g., acetabular, pubic rami, femoral neck), and displacement.
• Joint spaces: Evaluation for narrowing, widening, or irregularities suggestive of arthritis or joint effusion.
• Bone density: Assessing for signs of osteoporosis, osteopenia, or sclerosis.
• Soft tissue shadows: Identifying calcifications, gas, or abnormal masses.

Normal findings include intact bony cortices, symmetrical joint spaces, and absence of fractures or dislocations. Abnormal findings may suggest trauma, infection, degenerative changes, or neoplastic processes.

Common Pathologies Detected on Pelvis X-Ray

• Fractures: Most commonly of the pubic rami, acetabulum, sacrum, or proximal femur. Pelvic fractures can range from stable, low-impact injuries to complex, life-threatening disruptions.
• Arthritis: Osteoarthritis appears as joint space narrowing, subchondral sclerosis, and osteophyte formation. Inflammatory arthritis may show erosions or joint space loss.
• Tumours: Primary bone tumours (e.g., osteosarcoma, chondrosarcoma) or metastatic lesions may present as lytic or sclerotic areas, cortical destruction, or soft tissue masses.
• Infections: Osteomyelitis may manifest as periosteal reaction, bone lysis, or soft tissue swelling.
• Congenital or developmental abnormalities: E.g., hip dysplasia, Legg-Calvé-Perthes disease.

Risks and Safety: Radiation Exposure and Precautions

Pelvis X-rays use ionising radiation, which carries a small risk of tissue damage and increased lifetime cancer risk. However, the radiation dose from a single pelvis X-ray is generally low and considered safe when clinically justified. Key safety considerations include:

• Minimising exposure: Using the lowest effective dose and shielding sensitive areas.
• Pregnancy: Avoiding X-rays in pregnant women unless absolutely necessary.
• Children and young adults: Extra caution to limit cumulative radiation exposure.
• Informed consent: Patients should be informed about the benefits and risks before the test.

All radiology departments adhere to strict protocols to ensure patient safety and comply with radiation protection guidelines.

Alternatives: Other Imaging Modalities

While the pelvis X-ray is a valuable initial imaging test, other modalities may be considered depending on the clinical question:

• Computed Tomography (CT): Provides detailed cross-sectional images, especially useful for complex fractures, trauma, or tumour assessment.
• Magnetic Resonance Imaging (MRI): Superior soft tissue contrast, ideal for evaluating cartilage, ligaments, marrow abnormalities, or occult fractures.
• Ultrasound: Useful for assessing soft tissue masses, joint effusions, or guiding aspiration procedures, particularly in paediatric or pregnant patients.
• Nuclear Medicine Scans: Bone scans can detect infection, tumours, or occult fractures not visible on X-ray.

The choice of imaging depends on the clinical scenario, patient factors, and availability of resources.

Clinical Significance: Impact on Diagnosis and Management

The pelvis X-ray plays a pivotal role in the diagnostic workup and management of a wide range of conditions. Its rapid availability, low cost, and ability to detect significant pathology make it an essential tool in emergency, outpatient, and inpatient settings. Key contributions include:

• Prompt identification of fractures and dislocations, enabling timely orthopaedic intervention.
• Detection of degenerative or inflammatory joint disease, guiding medical or surgical therapy.
• Evaluation of neoplastic or infectious processes, prompting further investigation or specialist referral.
• Monitoring healing and post-operative outcomes in orthopaedic patients.

A normal pelvis X-ray can also provide reassurance and help exclude serious pathology in patients with non-specific symptoms.

Nursing Care for Patients Undergoing Pelvis X-Ray Diagnostic Procedure

Nurses are integral to the process, ensuring patient safety, comfort, and optimal outcomes, from preparation to post-procedure care.

2. Pre-Procedure Nursing Responsibilities

A. Patient Assessment and History

• Verify Identity: Confirm the patient’s identity using two identifiers (e.g., name and date of birth).
• Review Medical History: Assess for allergies (especially to contrast if applicable), current medications, pregnancy status, prior pelvic injuries or surgeries, and mobility limitations.
• Evaluate Pain and Mobility: Note any pain level, movement difficulties, or need for assistance in positioning.

B. Patient Education and Psychological Preparation

• Explain the Procedure: Describe the purpose, steps, and duration of the X-ray. Address common concerns and misconceptions, such as radiation exposure.
• Reassure and Support: Alleviate anxiety by answering questions, providing emotional support, and ensuring privacy.
• Obtain Informed Consent: Ensure the patient understands the procedure and consents to it, as per institutional policy.

C. Physical Preparation

• Remove Obstructions: Instruct the patient to remove clothing, jewelry, or metallic objects from the pelvis and lower abdomen, as these can interfere with image quality.
• Provide Gown: Offer a clean hospital gown and assist with changing if needed.
• Address Special Needs: For patients with mobility challenges, provide safe assistance and adaptive aids.
• Bladder Preparation: In some cases, ensure the bladder is empty to improve image clarity (follow institutional protocols).

D. Pre-Procedure Safety Checks

• Check for Pregnancy: For females of childbearing age, confirm pregnancy status to avoid unnecessary radiation exposure.
• Allergy and Sensitivity: Screen for allergies to contrast agents if contrast X-ray is ordered.
• Assess for Pain: Provide analgesia or comfort measures as needed prior to moving or positioning the patient.

3. Intra-Procedure Nursing Care

A. Positioning and Comfort

• Assist with Positioning: Help the patient onto the X-ray table and into required positions (usually supine), minimizing discomfort and ensuring optimal image acquisition.
• Immobilization: Use pillows, sandbags, or straps to maintain correct position, especially for trauma patients or children.
• Pain Management: Monitor for signs of pain or distress and intervene promptly.

B. Radiation Safety

• Shielding: Place lead aprons or shields over non-imaged areas, especially the gonads, to minimize radiation exposure.
• Staff Protection: Ensure staff either leave the room or stand behind lead barriers during exposure.
• Minimize Exposures: Confirm that only necessary images are taken and exposures are kept as low as possible.

C. Monitoring and Support

• Continuous Observation: Stay with the patient, especially those at risk of falls, agitation, or confusion.
• Communication: Provide clear instructions before each image and encouragement throughout the procedure.
• Emergency Preparedness: Be alert for sudden changes in patient condition (e.g., pain, allergic reaction to contrast, syncope) and know emergency protocols.

4. Post-Procedure Nursing Care

A. Immediate Post-Procedure Care

• Assist with Mobility: Help the patient off the X-ray table, especially if they are weak or in pain.
• Assess for Adverse Effects: Monitor for complications such as pain, dizziness, or allergic reactions (if contrast was used).
• Provide Comfort: Ensure the patient is dressed, comfortable, and oriented.
• Return Belongings: Assist the patient in retrieving personal items removed prior to the procedure.

B. Patient Education and Follow-Up

• Explain Next Steps: Inform the patient about when and how results will be available, and any further appointments or instructions.
• Encourage Questions: Provide opportunities for the patient to ask questions or discuss concerns.
• Advise on Activity: If pain or mobility issues persist, advise rest or limited activity as appropriate.
• Signs of Complications: Educate the patient on symptoms that warrant immediate medical attention (e.g., severe pain, swelling, bleeding, allergic reaction).

5. Special Considerations

A. Pediatric Patients

• Family Involvement: Allow a parent or caregiver to be present for reassurance, provided radiation safety measures are followed.
• Distraction Techniques: Use toys, videos, or conversation to reduce anxiety and encourage cooperation.
• Extra Shielding: Take additional steps to minimize radiation exposure.

B. Trauma and Critically Ill Patients

• Spinal Precautions: Maintain cervical spine immobilization if appropriate.
• Coordination: Work closely with radiology and emergency staff to minimize movement and expedite care.
• Pain Control: Anticipate and address pain promptly.

C. Pregnant Patients

• Risk-Benefit Assessment: Confirm the necessity of the procedure and explore alternatives if possible.
• Maximize Shielding: Apply lead shielding to the abdomen and pelvis.
• Documentation: Record pregnancy status and all precautions taken.

D. Patients with Disabilities

• Adaptive Support: Use assistive devices and enlist additional staff if needed for safe transfers and positioning.
• Communication: Adapt instructions to the patient’s cognitive or sensory abilities.

6. Documentation and Communication

• Record Keeping: Document assessment findings, education provided, consent, procedure details, patient response, and any complications.
• Interdisciplinary Collaboration: Communicate relevant information to radiology staff, physicians, and other team members.
• Reporting: Promptly report abnormal findings or adverse events.

7. Infection Control and Environmental Safety

• Hand Hygiene: Perform hand hygiene before and after patient contact.
• Clean Equipment: Ensure the X-ray table, positioning aids, and lead shields are cleaned between patients.
• Personal Protective Equipment (PPE): Use PPE as appropriate, especially with patients on isolation precautions.

8. Ethical and Legal Considerations

• Informed Consent: Ensure the patient understands the risks, benefits, and alternatives to the procedure.
• Privacy and Dignity: Maintain confidentiality and respect the patient’s privacy throughout the procedure.
• Advocacy: Act as the patient’s advocate, especially if they are unable to speak for themselves.

REFERENCES

1. American Academy of Orthopaedic Surgeons. Pelvic Fractures (https://orthoinfo.aaos.org/en/diseases–conditions/pelvic-fractures/). Accessed 7/18/2022.
2. FDA. X-Rays, Pregnancy and You (https://www.fda.gov/radiation-emitting-products/medical-x-ray-imaging/x-rays-pregnancy-and-you). Accessed 7/18/2022.
3. Radiological Society of North America, Inc. X-ray (Radiography) — Bone (https://www.radiologyinfo.org/en/info/bonerad). Accessed 7/18/2022.
